NEW · PESO approval series P675044

PESO Certified Cable Glands, Reducers & Stopping Plugs

Seven Exgrip products for explosive atmospheres now carry PESO certification: two cable glands and five fittings, made in Jamnagar and also certified under ATEX and IECEx.

E1FW

Cable gland

RED & ADP

Reducer / adapter

PLG

Stopping plug

7

PESO certified products

One approval series

2

Cable glands

E1FW and A2F

5

Fittings

Reducers, adapters, plugs

8

PESO certificate numbers

P675044/1 to P675044/8

The Achievement

The whole cable entry, certified by one manufacturer

In a flameproof enclosure, the gland, any reducer or adapter, and every stopping plug sit in the flame path. Exgrip’s PESO certification now covers each of those parts, so an entry can be specified and documented from a single source.

Gland to stopping plug

Cable glands, reducers, adapters and stopping plugs are all in the certified range.

Ready for documentation

Every product lists its PESO, ATEX and IECEx numbers for vendor document submittals.

Gas group IIC and dust IIIC

All seven are certified Ex db / Ex eb IIC Gb and Ex ta IIIC Da. Five also cover Group I mining.

Made in Jamnagar

Brass, nickel plated brass and stainless steel 304, 316L and 316 across the range.

Certified Product Portfolio

Exgrip's PESO certified products

Choose a product to see its full datasheet, thread options and ordering codes.

Cable Glands

2 products · PESO P675044/1 and /2

PESO CERTIFIED

E1FW

Double Compression Cable Gland

PESO certificate P675044/2

PESO CERTIFIED

A2F

Single Compression Cable Gland

PESO certificate P675044/1

Fittings

5 products · PESO P675044/3 to /8

PESO CERTIFIED

RED & ADP

Reducers & Adapters

PESO P675044/8 (RED) · P675044/3 (ADP)

PESO CERTIFIED

PLG

Hexagonal Head Stopping Plug

PESO certificate P675044/4

PESO CERTIFIED

PLD

Dome Allen Key Type Stopping Plug

PESO certificate P675044/5

PESO CERTIFIED

YADP

Dual Entry Y Adapter

PESO certificate P675044/7

PESO CERTIFIED

90° ADP

90 Degree Adapter

PESO certificate P675044/6

Certification Register

Certificate numbers for every product

Each product carries its own PESO number alongside its ATEX and IECEx certificates. The numbers below match the technical information on each product page.

PESO

ATEX

IECEx

IP66 / IP67 / IP68

Product	PESO	ATEX	IECEx
A2F Single compression gland	P675044/1	ETL25ATEX0489X	IECEx ITS 25.0006X
E1FW Double compression gland	P675044/2	ETL25ATEX0489X	IECEx ITS 25.0006X
ADP Adapters	P675044/3	ETL25ATEX0489X	IECEx ITS 25.0006X
PLG Hexagonal head stopping plug	P675044/4	ETL25ATEX0489X	IECEx ITS 25.0006X
PLD Dome / allen key stopping plug	P675044/5	ETL25ATEX0489X	IECEx ITS 25.0006X
90° ADP 90 degree adapter	P675044/6	ETL24ATEX0474U	IECEx ITS 24.0050U
YADP Dual entry Y adapter	P675044/7	ETL24ATEX0474U	IECEx ITS 24.0050U
RED Reducers	P675044/8	ETL25ATEX0489X	IECEx ITS 25.0006X

Where These Products Fit

Built for flameproof and increased safety enclosures

Glands, reducers, adapters and stopping plugs are fitted wherever a cable enters equipment in a hazardous area.

Oil & Gas and Refineries

Zone 1 and Zone 2 gas areas, including the Jamnagar refinery belt

Chemical Plants

Gas and combustible dust areas; stainless steel options for corrosive sites

Marine & Offshore

Hazardous zones on platforms and terminals, in nickel plated brass or stainless steel

Looking for PESO certified cable glands and fittings?

Send the entry thread sizes, protection concept and cable details for each enclosure. Exgrip’s engineers will specify the gland, reducer or adapter and stopping plugs, with certificate numbers for your documents.
